Gotrax GXL V2 User Manual

Before folding the scooter, make sure that the scooter is powered off. .
Folding: Ensure the electric scooter is powered off, hold the tiller and pull out the
spring pin on the right folding panel then rotate the spring pin counterclockwise. Insert
the hook on the tiller into the loop on the rear fender buckle. You may hear a click
which indicates that you were successful in folding and locking the scooter.
Unfolding:
mechanism.
Putting Your Scooter
Away/Folding
1 2

Gotrax GXL V2 Specifications

General

Top Speed	15.5 mph
Motor	250W
Battery	36V 5.2Ah
Weight	26.4 lbs
Max Load	220 lbs
Foldable	Yes
Display	LED display
Range	12 miles
Tires	8.5 inches
Brakes	Disc Brake
Charging Time	4 hours
