Gotrax XR Ultra User Manual

Before folding the scooter, make sure that the scooter is pow ered off.
Folding: Ensure the electric scooter is pow ered off, hold the tiller and pull out the
spring pin on the right folding panel then rotate the spring pin counterclockwise. Insert
the hook on the tiller into the loop on the rear fender buckle. You m ay hear a click
which indicates that you w ere successful in folding and locking the scooter.
U nfolding:
me chanism.
Putting Your Scooter
Away/Folding
1 2

Gotrax XR Ultra Specifications

General

Motor	300W
Max Speed	15.5 mph (25 km/h)
Max Load	220 lbs (100 kg)
Charging Time	4-5 Hours
Foldable	Yes
Tires	8.5" Pneumatic Tires
Brakes	Disc Brake
Range	17 miles
