GPI FLOMEC QM Series User Manual

-----------------------------------------------------------------------------------
5
QM40 Modular Configurations
figure 4a
-----------------------------------------------------------------------------------------------------
figure 4c
figure 4b
inlet adapter/o-ring/bolts
outlet adapter/o-ring/bolts
90
o
outlet adapter/o-ring/bolts
pump with modular outlet
90
o
outlet adapter/o-ring/bolts
pump with modular outlet
modular filter adapter/o-rings/bolts
filter
The QM40 includes adapter plates, o-rings, and
bolts for use with threaded pipe.
Without the inlet adapter plate, the QM40 can
be bolted directly to the outlet of a GPI or GPro
pump featuring a modular outlet. Bolt modular
accessories to the outlet of the QM40 or use the
outlet adapter plate for threaded pipe.
Use a GPI modular filter adapter to include a
filter into your system.
