GPRINTER GP-1124D - Internal

Internal
Note: Picture showing printer port is for GP-1125D.
Label paper fixing stand
Label paper supply hub
Push button for thermal
print head open
Top cover
2.2.3 The bottom
RS-232C serial port
DIP switch
Label entrance from
external holder
Push button for thermal
print head open
Power port
USB port
