GPS1195 Auto Gate Manual Version 3
Connector 5 (Relay Contacts)
Terminal 1 – Relay 1 contact 2 – Common
Terminal 2 – Relay 1 contact 2 – Normally Closed
Terminal 3 – Relay 1 contact 2 – Normally Open
Terminal 4 – Relay 2 contact 2 – Common
Terminal 5 – Relay 2 contact 2 – Normally Closed
Terminal 6 – Relay 2 contact 2 – Normally Open
Terminal 7 – Relay 3 contact 2 – Common
Terminal 8 – Relay 3 contact 2 – Normally Closed
Terminal 9 – Relay 3 contact 2 – Normally Open
Terminal 10 – Relay 4 contact 3 – Common
Terminal 11 – Relay 4 contact 2 – Normally Open
Terminal 12 – Relays 1 – 4 coil common (24Vdc common)
Connector 6 (Detector Loops and 24Vdc Supply)
Terminal 1 – Free detector loop
Terminal 2 – Free detector loop
Terminal 3 – Close detector loop
Terminal 4 – Close detector loop
Terminal 5 – Arming detector loop
Terminal 6 – Arming detector loop
Terminal 7 - +24Vdc
Terminal 8 - +24Vdc
