GPS1195 Auto Gate Manual Version 3
Terminal 9 – +24Vdc
Terminal 10 – 24Vdc common
Terminal 11 – 24Vdc common
Terminal 12 – 24Vdc common
Dip Switch Settings
Switch 1 – On = Reset Loop Enabled
Switch 1 – Off = Reset Loop Disabled
Switch 2 – On = Free Loop Enabled
Switch 2 – Off = Free Loop Disabled
Switch 3 & 4 – 3 is Off, 4 is Off – Arming & Lockout
Switch 3 is On, 4 is Off = Arming only
Page 8E
