GPS1195 Auto Gate Manual Version 3
Trouble shooting
Safety Edge
When the barrier arm reverses up Input 10 flashes and output 1 flashes once
When the up switch is made Input 4 lights up and holds
There is a 45 second delay before the arm resets
Input 3 is the down limit switch
Input 4 is the up limit switch
Auto / Manual switch
In Auto mode as the arm goes down output 0 lights up Inputs 0 1 2 3 4 5
Input 4 and 5 drop out. When the down switch is made output OOOO O O
0 drops out and input 3 lights up Outputs OOOOOOO O
PR E S 0 1 2 3
In manual mode as the arm goes up input 5 and output 1 light up Inputs 0 1 2 3 4 5
Input 3 drops out as the arm rises and input 5 lights up when the OOOO O O
Up limit switch is made input 4 + 5 lights up Outputs OOOOOOO O
PRE S 0 1 2 3
Page 15B
