GPS1195 Auto Gate Manual Version 3
Trouble shooting
Latching Keyswitch
When you latch the keyswitch to open the barrier arm input 5 and output 1 light up
Output 1 drops out and input 4 and 5 stay lit when the up switch is made
When you release the latching keyswitch input 4 and 5 drop out,
Output 0 lights up and when the down switch is made output 0 drops out and input 3 stays on.
Down Position Inputs 0 1 2 3 4 5
OOOOO O
Outputs OOOOOOO O
P R E S 0 1 2 3
Up Position Inputs 0 1 2 3 4 5
OOOOO O
Outputs OOOOOOO O
PR E S 0 1 2 3
Page 15D
