DIGITAL TO ANALOG CONVERTER FIXED OUTPUTS
Output Levels
0dBFS +16dBu / (+24dBu*)
Fixed output trim range (0.5dB steps) -95.5dB to +30dB
THD+N
1kHz, -1dBFS, 20-22kHz bandwidth 0.002%
Dynamic Range
20-22kHz bandwidth >111dB
Input Lock Range
AES3/SPDIF 32kHz to 192kHz
TOSLINK 32kHz to 96kHz
ADAT LIGHTPIPE™ 30kHz 55kHz
s-Lock™ Sample Clock Intrinsic Jitter
20-22kHz bandwidth <25ps
s-Lock™ Sample Clock Jitter Rejection
1kHz sine jitter -40dB
s-Lock™ Supported Sample Rates
AES3, SPDIF 44.1, 48, 88.2, 96, 176.4, 192kHz
TOSLINK 44.1, 48, 88.2, 96kHz
ADAT LIGHTPIPE™ 44.1, 48kHz
s-Lock™ Capture Range
44.1, 48kHz +/- 10Hz
88.2, 96kHz +/- 20Hz
176.4, 192kHz +/- 40Hz
Word Clock / Superclock Input
Impedance (switchable) 75 Ohms / 1M Ohms
Minimum Voltage 3V peak to peak
Maximum Voltage 5V peak to peak
Word clock frequencies supported 44.1, 48, 88.2, 96, 176.4, 192kHz
Superclock frequencies supported 11.2896MHz, 12.288MHz (256x fs)
POWER SUPPLY / GENERAL
Power consumption 40W
Input Voltage 50-60Hz 100, 120, 220-230, 240VAC
Dimensions
Main chassis IEC 2U 3.5” x 10.5” x 17”
Remote control unit 1.6” x 8” x 5.25”
Power supply unit 1.7” x 8.5” x 8.5”
Weight
Main chassis 14.1lbs / 6.4kg
Remote control unit 2.3lbs / 1kg
Power supply unit 6.5lbs / 2.9kg
* available via optional jumper setting, please consult with factory.
