S/PDIF STEREO INPUT This RCA jack input accepts a S/PDIF format digital stereo signal.
TOSLINK STEREO INPUT This optical connector accepts a TOSLINK format digital stereo
signal.
AES3 MULTI-CHANNEL INPUT This DB25 female connector accepts inputs from four AES3
format digital sources. The rst three AES3 inputs serve as the 5.1 digital input source
(channels 1 through 6) and the remaining pair is available as the second 2 CH AES3 input
(channels 7 and 8). Wired to the Tascam DA-88 standard pinout.
TB MIC INPUT This female XLR connector connects a talkback microphone to the m906 for
control room to studio communications. 48 Volt phantom power is provided.
5.1 UNBALANCED ANALOG INPUTS These six RCA jacks are used to input an unbalanced
(–10dBV) 5.1 source into the m906.
REMOTE CONNECTOR This female DB15 (high density) connector allows connection
between the m906 mainframe and the remote control unit via the supplied remote cable.
TB SW JACK This ” TRS talkback switch jack is for connecting an external switch used to
remotely activate the talkback microphone function.
CR OUT 1 and CR OUT 2 Analog, balanced stereo outputs for stereo control room output
sets #1 and #2. These connections are wired in parallel with the left and right outputs of the
corresponding 5.1 DB-25 control room outputs.
CUE OUT LEFT AND RIGHT An analog balanced stereo output for the CUE input signal. The
talkback microphone signal is summed into this output. This output can also be congured
to serve as a third stereo control room output pair.
CUE IN LEFT AND RIGHT This input is for connecting a stereo cue signal to the m906, which
can be routed to the stereo cue outputs for studio talent monitoring and be monitored
directly in the control room.
2 CH 1 and 2 CH 2 INPUT These are balanced analog stereo XLR inputs.
5.1 BALANCED ANALOG INPUTS This DB25 female connector accepts analog balanced
(+4dBu) signals for use as a 5.1 source input.
