page 15
Specs
Headphone output, volume at maximum 0dB
Balanced Line output, volume at maximum +4dB
Unbalanced Line output, volume at maximum -8dB
@ 0dBu out +/- .25dB 27Hz – 54kHz
@ 0dBu out +/- .5dB 18Hz – 80kHz
@ 0dBu out +/-3dB 6.5Hz – 226kHz
Balanced Input +22dBu
Unbalanced Input +16dBu
Unbalanced output @1kHz, 100k Ohm load +21.5dBu
Balanced output @1kHz, 100k Ohm load +27dBu
Headphone output @1kHz, 50 Ohm load +20dBu
Balanced Input 106K Ohms
Unbalanced Input 53K Ohms
Balanced Output 95 Ohms
Unbalanced Output 47.5 Ohms
Headphone Output 1.2 Ohm
@ 0dB gain, Balanced In > Balanced Out 117dB
@ 0dB gain, Balanced In > Headphone Out 116dB
Headphone Out @ +10dBu, 50 Ohm load, SMPTE 4:1 <0.020%
Headphone Out @ +10dBu, 50 Ohm load <0.0060%
Unbalanced Line Out @ +10dBu, 100k Ohm load <0.00026%
Balanced Line Out @ +20dBu, 100k Ohm load <0.00036%
Channel matching <0.05dB
Attenuator Range 97.5dB
Balanced Output, volume at maximum, 22-22kHz -90dBu
Balanced Output, volume at minimum, 22-22kHz -103dBu
Unbalanced Output, volume at maximum, 22-22kHz -101dBu
Unbalanced Output, volume at maximum, 22-22kHz -105dBu
Input Sample Rate 32, 44.1, 48, 88.2, 96, 176.4, 192kHz
44.1kHz, 24bit, 1kHz, -1dBFS, Unbalanced Out @ +15dBu <0.0009%
44.1kHz, 24bit, 1kHz, -1dBFS, Balanced Out @ +15dBu <0.0006%
Unbalanced Output @ 0dBFS, Volume at maximum, trim at 0 +9dBu
Blanced Output @ 0dBFS, Volume at maximum, trim at 0 +21dBu
120VAC 0.16A
230VAC 0.08A
Dimensions H1.7” x W8.5” x D8.25”
Weight 5 lbs (2.2kg)
