308–167
DIMENSIONS
6.0 in. (152 mm)
2.31 in.
(59 mm)
1.38 in.
(35 mm)
Model 104–266, 104–267
(1/2 in. Port)
6.0 in. (152 mm)
2.31 in.
(59 mm)
1.38 in.
(35 mm)
Model 110–234 (3/8 in. Port)
6.0 in. (152 mm)
2.31 in.
(59 mm)
1.38 in.
(35 mm)
Model 171–937 (1/2 in. Port)
0.5625 in.
(14 mm)
1.5 in.
(38 mm)
3 in. (80 mm)
4.1 in. (104 mm)
1.61 in.
(41 mm)
1.125 in.
(28.6 mm)
3.0 in. (88 mm)
1.56 in.
(40 mm)
0.5 in.
(13 mm)
Model 104–815 (1/8 in. Port)
Model 1 10–341 (1/8 in. Port)
Model 1 11–804 (1/4 in. Port)
Model 1 10–318 (1/4 in. Port)
1-13/16–18
1-13/16–18
1-3/4–18
1-3/4–18
1-3/4–18
1-13/16–18
FLOW CUR VES





 

Air Flow (SCFM)
100 PSIG Supply
Model 104–266, 104–267, 171–937 (1/2 in. Port)
Model 1 10–234 (3/8 in. Port)





     

Air Flow (SCFM)
100 PSIG Supply
Model 104–815 (1/8 in. Port)
Model 1 10–318 (1/4 in. Port)
For Model
1 10–318 only





        

Air Flow (SCFM)
100 PSIG Supply
Model 110–341 (1/8 in. Port)
Model 1 11–804 (1/4 in. Port)
