308–167
REPAIR KIT DRAWINGS
ADJUSTING KNOB
SPRING
HOUSING
T
orque to
45 in-lb
(51 N.m)
COMPRESSION
SPRING
ADJUSTING SCREW
NUT
DIAPHRAGM
DISC
COMPRESSION
SPRING
Knob Kit 104–816
Diaphragm Kit 104–817
FOR REGULA T ORS 104–815, 1 10–318
ÇÇ
Ç
ÇÇ
Ç
Ç
ÇÇ
ÇÇ
ÇÇ
Ç
ÇÇ
ÇÇ
Ç
ÇÇ
ÇÇ
Ç
ÇÇ
ÇÇ
Ç
T–HANDLE
LOCKNUT
SPRING
GUIDE
SPRING
SPRING HOUSING
T
orque to
45 in–lb
(51 N.m)
BODY
(not included)
O–RING
DISC
SPRING
O–RING
CAP
T
orque to
45 in–lb (51 N.m)
T–Handle Kit
106–173
DIAPHRAGM
V alve Kits
180–780
for regulator 104–267
180–781
for regulator 171–937
180–782
for regulators 104–266,
110–234
Cap Kit 104–695
0926
FOR REGULA TORS
104–267, 171–937,
104–266, 1
10–234
O-RING
FOR REGULA T OR 1 10–341, 1 11–804
Piston Kit 223–164
STEM & DISK
PISTON
SEAT
