Technical Data
16 306674W
Technical Data
.
50:1 Fire-Ball 425 Pumps
US Metric
Maximum fluid working pressure 7500 psi 51.7 MPa, 517 bar
Air pressure operating range 40 to 150 psi 0.3 to 1 MPa, 3 to 10 bar
Fluid pressure ratio 50:1
Maximum delivery
0.5 gpm
1.9 lpm
Cycles per gallon (per liter) 110 28
Maximum recommended pump speed 60 cycles per minute
Air motor effective diameter 4.25 in. 108 mm
Stroke 4 in. 102 mm
Air consumption approximately 19 cfm at 1
gpm at 70 psi
approximately 0.53 m
3
/min at
3.8 lpm at 0.48 MPa, 4.8 bar
Wetted parts Steel, brass, aluminum, leather
Weight
Model 205394 34 lb 15 kg
Model 205395
37 lb 17 kg
