Table
of Contents
Warnings 2.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setup/Operation 5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parts
Drawing and Parts List
10.
. . . . . . . . . . . . . . . . . . .
Technical
Data
11.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warranty 12
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Graco
Phone Numbers
12.
. . . . . . . . . . . . . . . . . . . . . . . .
Symbols
Warning Symbol
WARNING
This
symbol alerts you to the possibility of serious
injury or death if you do not follow the instructions.
Caution Symbol
This
symbol alerts you to the possibility of damage to
or destruction of equipment if you do not follow the
instructions.
EQUIPMENT MISUSE HAZARD
Equipment
misuse can cause the equipment to rupture or malfunction and result in serious injury
.
D
This equipment is for professional use only
.
D
Read all instruction manuals, tags, and labels before operating the equipment.
D
Use the equipment only for its intended purpose. If you are not sure, call your Graco distributor
.
D
Do not alter or modify this equipment. Use only genuine Graco parts and accessories.
D
Check equipment daily
. Repair or replace worn or damaged parts immediately
.
D
Do not exceed the maximum working pressure stated on the equipment or in the
T
echnical Data
for your equipment. Do not exceed the maximum working pressure of the lowest rated component
in your system.
D
Use fluids and solvents which are compatible with the equipment wetted parts. Refer to the
Tech-
nical Data
section of all equipment manuals. Read the fluid and solvent manufacturer
’
s warnings.
D
Handle hoses carefully
. Do not use hoses to pull equipment.
D
Route hoses away from traffic areas, sharp edges, moving parts, and hot surfaces. Do not expose
Graco hoses to temperatures above 66
_
C (150
_
F) or below –40
_
C (–40
_F).
D W
ear hearing protection when operating this equipment.
D
Do not lift pressurized equipment.
D
Comply with all applicable local, state, and national fire, electrical, and safety regulations.
