307965 5
Installation
These meters must be installed in-line as part of a dispense system as shown in Fig. 1; however, the typical instal-
lation shown is only a guide for selecting and installing an in-line meter. It is not an actual system design. Contact
your Graco representative for assistance in designing a system to suit your needs.
Fig. 1
A
B
C
KEY
A In-line meter
B In-line strainer
C Shutoff valve
D Pressure relief valve
E Check valve
F Bleed–off valve
2251
D
E
F
