Operation
For Maximum Dispensing Accuracy
(gallon/quart/pint meter only)
Set the meter to dispense in pints or quarts when
dispensing 1 gallon or less.
Always press the RESET key pad to clear the meter
before a new dispense cycle.
QTS
PTS
PINTS
QUARTS
GALLONS
GAL
GAL
GAL
GRACO
Press RESET to
clear
TOTAL RESET
EXAMPLE OF ACCUMULATED TOTAL
DIGITAL DISPLAY
EXAMPLE OF MEASUREMENT UNITS
Fig. 2
Fig. 3
Fig. 4
QTS
Fig. 5
EXAMPLE OF TOTAL FOR
LAST DISPENSE CYCLE
To Next Page
