Service
Cross Sectional Reference
Pump 287512
ti6196a
Pump 287512
Fig 19
223
203
218
208
217
213
214
204
221
224
205
219
215
212
227
222
202
221
216
206
210
201
220
228
207
229
2
V-Maxt UHWMPE, blue
V-Maxt UHWMPE, blue
Leather
Leather
V-Maxt UHWMPE,
brown on 249122,
289590
211
Only on
249122,
289590,
24M416
Technical Data
Maximum working pressure 3300 psi.....................
(228 bar, 22.8 MPa)
Fluid inlet size 1-5/16 npt(m)............................
Fluid inlet size (287579, 287929, 24M416) 1 in. npsm(m)...
Fluid outlet size 3/8 npt(f)....................
Wetted parts stainless steel, PTFE,......................
leather, nylon, zinc-plated carbon steel,
tungsten carbide, brass, fluoroelastomer,
acetal, polyethylene
