Graco 24S134 - Spray Disc and Nozzle Selection

Setup
3A3373C 7
Spray Disc and Nozzle Selection
• Standard nozzles (4) are numbered 3, 4,
6, 8, 10 and 12, designating orifice size
in millimeters. These parts can be
interchanged to produce a pattern
suitable for each job.
• For smaller droplet sizes, reduce nozzle
(4) and/or disc (2) size and increase gun
atomizing air by opening air valve (A)
(counter-clockwise).
• For larger droplets, increase nozzle (4)
and/or disc size (2) and reduce gun
atomizing air by closing air control valve
(A) (clockwise).
Recommended Nozzle & Disc Selection Charts
Nozzle
WideTex™ Disc
Application Nozzle Size
2
Air Volume
1
Application Nozzle Size
2
Air Volume
1
Fog 3 mm high Knockdown 6-12 mm low
Simulated
Acoustic
4 mm medium to high Textured
Elastomerics
8-12 mm
high
3
6 mm Plastics 8-10 mm
high
3
8-10 mm EIFS 8-12 mm
high
3
Orange peel 3-4 mm medium to high Stucco 10-12 mm
high
3
4-8 mm Knockdown 6-12 mm low
Splatter coat 6-8 mm low to medium
6-10 mm
1
Control air volume with gun air control valve.
2
For more material volume try a larger orifice tip.
3
Some materials may require the addition of external air to improve production rate.
Use External Air Hookup Kit 287328.
Application WideTex Disc Nozzle (mm) Air Volume
Standard Hardened
Simulated Acoustic - Fine W6 W6H 4 high
- Medium W8 W8H 6 high
- Coarse W10 W10H 8- 10 high
Fog W4 W4H 3 high
Orange peel W4 or W6 W4H or W6H 3 - 8 medium to high
Splatter coat W6 or W8 W6H or W8H 6 - 10 low to medium
Knockdown W6 or W8 W6H or W8H 6 - 8 low
