Operation
311304C 7
Operation
On/Off switch lever (8d) is located under nozzle holder.
Remove nozzle before turning pump on.
1. Move switch lever (8d) on.
2. Insert nozzle into tank and actuate nozzle lever to
dispense fuel.
3. Immediately after fueling turn switch lever (8d) off.
Maintenance
1. Clean inlet strainer (3b) after every 50 hours of
operation.
2. To remove inlet strainer (3b), remove four screws
(3c) and strainer cover (3a). Remove and clean
strainer.
3. If strainer is excessively dirty, clean tank to protect
pump and the equipment being fueled.
4. After cleaning strainer, replace strainer and cover.
Make sure cover seal (3d/7e) is in place.
Before servicing, turn pump off and open the
nozzle to relieve pressure.
CAUTION
Do not operate pump dry. Do not run pump for more
than 5 minutes with nozzle closed. Do not operate
pump for more than 30 minutes continuously in 1 hour.
