Repair
8 334654B
7. Clean and inspect parts. (The piston has
a special thread locking/sealing patch.
Do not remove the patch. The patch
allows for disassembly/assembly
procedures before it is necessary to
apply thread sealant to the threads. On
fifth assembly apply thread sealant to
threads.
8. Remove and discard throat packing and
glands from the cylinder.
ti25172a
ti25173a
