14. Make sure indicator is showing "green"
on both sides. This will confirm base is
securely locked with ISOFIX mountings.
15. Push base hard against seat back until it
locks with an audible "click". The black
frame should remain tight against seat back.
16. Adjust height of support leg by pulling
red knob. Make sure support leg is solid
against vehicle floor. Support leg should
be adjusted so base is resting on vehicle seat.
Now, continue installing seat on page 19.
17. NOTE!! DISASSEMBLY! Lift red lock so
tension in base is released. Make sure the
yellow arrows point against each other.
18. NOTE!! DISASSEMBLY! Lift ISOFIX buttons
on both sides and pull in direction of red
arrows until indicator show red.
