27. Secure base according to picture 19-21.
Pull seat belt as far as possible and secure in
its regular buckle. Pull seat belt under the
black frame.
28. Thread seat belt through blue clips on
both sides.
29. Push down on base and simultaneously
tighten seat belt. Make sure seat belt is tight
and holding base firmly in place.
30. Adjust height of support leg by pulling
red knob. Make sure support leg is solid
against vehicle floor. Support leg should
be adjusted so base is resting on vehicle seat.
Now, continue installing seat on next page.
31. If head protection is installed, pull up to
top position.(See page 11 for information
about head protector.
32. Pull handles up on both sides.
33. Put handles together by pulling towards
middle and fasten handles to each other.
NOTE!! BE CAREFUL WITH HEAD OF CHILD!
34. Insert seat according to picture then
rotate 90 degrees.
With lap belt (middle rear)
