Parts
309550U 35
* These parts are only available in repair kits. To select
a kit, refer to page 38.
† These parts are not available singly.
‡ Included in Front End Replacement Kit 246361.
★ Included in Safety Stop Assembly 248064 (includes
1 of item 24).
▲ Replacement Danger and Warning labels, tags, and
cards are available at no cost.
◆ Included in Spatter Tip Kit 248414 (see page 36).
Ref.
No. Part No. Description Qty
1 15B201 HANDLE 1
2 15B208 PLUG, air valve 1
3
‡ 248137 O-RING; PTFE; package of 6 1
4
★ 15B206 LOCK, safety 1
5
★ 15B204 CAP, cylinder 1
6 192272 PIN 1
7
‡ 15B215 RING, lock 1
8‡ 15B223 VALVE, cleanoff air 1
9
‡ 15B211 RING, retaining 1
10
‡ 15B210 AIR CAP; for round pattern guns 1
15B801 AIR CAP; for flat pattern guns;
not included in Front End Replace-
ment Kit 246361; see Detail
Views, page 36
1
◆ 15D973 AIR CAP, for spatter pattern gun;
not included in Front End Replace-
ment Kit 246361; see Detail
Views, page 36
1
11
‡ 246491 HOUSING, fluid 1
12 246012 MANIFOLD, fluid, 2-hose;
includes 12a-12g
1
249523 MANIFOLD, fluid, 4-hose;
includes 12a, 12b, 12d-12g, 50;
see Detail Views, page 36
1
12a
† .MANIFOLD 1
12b 246356 . VALVE, fluid 2
12c 100139 . PLUG, pipe; 1/8-27 npt 2
12d 15B221 . BOLT; 5/16-24 1
12e 117634 . SWIVEL, B side; 1/8 npt(m) x
no. 6 JIC(f); for 2-hose manifold
1
117634 . SWIVEL, B side; 1/8 npt(m) x
no. 6 JIC(f); for 4-hose manifold;
see Detail Views, page 36
2
12f 117635 . SWIVEL, A side; 1/8 npt(m) x
no. 5 JIC(f); for 2-hose manifold
1
117635 . SWIVEL, A side; 1/8 npt(m) x
no. 5 JIC(f); for 4-hose manifold;
see Detail Views, page 36
2
12g 15B993 . SPRING, ring, lock 1
13 15B209 TRIGGER 1
14*
★ 248136 O-RING, cylinder cap;
package of 6
1
15 15B203 PISTON 1
16* 248135 O-RING, piston; package of 6 1
17* 248134 O-RING, piston shaft;
package of 6
1
18
‡ 246349 CARTRIDGE, seal, A side, SST;
includes 18a-18e
1
246350 CARTRIDGE, seal, B side, SST;
includes 18a-18e
1
18a
† . CARTRIDGE BODY 1
18b 117491 . SPRING 1
18c*
† . SEAL KIT; see page 41 1
18d* 248130 . O-RING, cartridge body;
package of 6
1
18e* 248128 . O-RING, side seal;
package of 6
1
19 CHAMBER, mix, round; see
Round Pattern Guns, page 37
1
CHAMBER, mix, flat;
see Flat Pattern Guns, page 37
1
20 15C480 WASHER, wave 1
21
‡* 248132 O-RING; package of 6 1
22 119626 MUFFLER 1
23
‡* 248131 O-RING; package of 6 1
24
‡*★ 246354 O-RING; package of 6 1
25
‡ 100846 FITTING, grease 1
26
‡ 246731 VALVE, check, A side; includes
26a-26g
1
246352 VALVE, check, B side; includes
26a-26g
1
26a
‡† .HOUSING 1
26b
‡† 15B214 . SCREW; 5/16-18 x
1/2 in. (13 mm)
1
26c
‡ 104396 . BALL; carbide 1
26d
‡ . SCREEN; see page 38 1
26e
‡ 117490 . SPRING 1
26f‡* 248133 . O-RING, check valve face;
package of 6
1
26g
‡* 248129 . O-RING, check valve housing;
package of 6
1
27
‡ 116550 RING, retaining 1
28
★ 15B205 STOP, piston 1
29 203953 SCREW; 10-24 x 3/8 in. (10 mm) 1
30
★ 114070 SPRING 1
31 117485 SPRING 1
32 15B202 SPOOL, valve 1
33 100721 PLUG, pipe; 1/4-18 npt;
round and flat pattern guns only
1
35 117509 QUICK-DISCONNECT, male, air;
1/4 npt(m); round and flat pattern
guns only
1
36▲ 222385 CARD, warning; not shown 1
37
‡ 15B689 COVER, grease fitting 1
39 FTxxxx TIP, flat; see Flat Tip Kits,
page 38
1
40* 246360 O-RING; PTFE; flat tip models
only; package of 3;
See Flat Pattern Guns, page 37
1
43 117661 VISE, pin; dual reversible chucks;
see Supplied Tools, page 36
1
46 117792 GREASE GUN; not shown 1
47 117510 COUPLER, air line 1
49 15B772 HOSE, air; 1/4 npsm (fbe);
18 in. (0.46 m)
1
50 112307 ELBOW, street; 1/8 npt (m x f);
round and flat pattern guns only
2
51 15B565 VALVE, ball; 1/4 npt (m x f); round
and flat pattern guns only
1
See Detail Views, page 36, for additional parts.
