Pump Parts
Model 226040, Series G
Stainless Steel, PTFE Packed
106
118**
107**
103
119
120
115
107**
108**
114
109
104**
112**
**105
117
116*
110
111**
111**
113*
131
132
101
AA
134**
150
TORQUE TO
30-35 ft-lb
(41-48 N•m)
LIPS FACE DOWN
LIPS FACE UP
GROOVES
FACE UP
LIPS FACE
DOWN
TORQUE TO
20-25 ft-lb
(27-34 N•m)
GROOVES
FACE DOWN
LIPS FACE UP
LIPS FACE
DOWN
