Graco G Series User Manual

18 307026
Dimensions
A
B
(Adjustable)
1/4 npt(f)
AIR INLET
1/2 npt(f)
FLUID OUTLET
2” npsm
3/4 npt(f)
FLUID INTAKE
(MODEL 223954
ONLY)
3/8 npt(f)
RETURN
Pump No.
A
Overall Length
B
Pump Length Weight
226040 50.25 in
(1276 mm)
32.375-33.875 in.
(822-860 mm)
17 lb (7.7 kg)
223954 30.5 in.
(775 mm)
13.70-14.10 in.
(348-358 mm)
1.5 lb (5.2 kg)
