Accessories
Water Sandblasting Kit 800120
Kit used for abrasive cleaning of stubborn dirt and
paint. Abrasive spray tip not included in kit. Use
abrasive spray tip as follows:
Model 1535 use 805325,
Model 2030 use 805313,
Model 2540 use 805321,
Model 3040 use 805317.
Antifreeze Flush Kit 802327
Kit used to flush systems with 50% anti-freeze solution
prior to storage or transport in freezing temperatures.
Technical Data
Model 804560 Model 804561 Model 804562 Model 804563
Engine
(4 cycle, air cooled)
5.5 HP Honda OHV 5.5 HP Honda OHV 9 HP Honda OHV 11 HP Honda OHV
Gasoline Tank Capacity 3.8 quarts (3.6 liter) 3.8 quarts (3.6 liter) 6.2 quarts (6.1 liter) 6.9 quarts (6.5 liter)
Water Pump Maximum Working
Pressure
1500 psi (10.2 MPa,
102 bar)
2000 psi (13.8 MPa,
138 bar)
2500 psi (17.2 MPa,
172 bar)
3000 psi (20.7 MPa,
207 bar)
Water Pump Maximum Flow 3.5 gpm (13 lpm) 3 gpm (11 lpm) 4 gpm (15 lpm) 4 gpm (15 lpm)
Inlet Hose Connection 3/4” garden hose (f) 3/4” garden hose (f) 3/4” garden hose (f) 3/4” garden hose (f)
Weight (without gun and hose) 79 lb (36 kg) 79 lb (36 kg) 110 lb (50 kg) 128 lb (58 kg)
Dimensions
Length
Width
Height
34.5” (940mm)
22” (483mm)
23.5” (508mm)
34.5” (914mm)
22” (533mm)
23.5” (572mm)
34.5” (914mm)
22” (533mm)
23.5” (572mm)
34.5” (914mm)
22” (533mm)
23.5” (572mm)
Maximum Inlet Water
Temperature
160_F (70_C) 160_F (70_C) 160_F (70_C) 160_F (70_C)
Sound data ISO 3744(CE1.5.8)
sound power
sound pressure
103.5 dB
93.1 dB
103.5 dB
93.1 dB
104.7 dB
94.3 dB
106.3 dB
95.8 dB
Wetted Parts
High Pressure Hose
Bypass Hose
Pressure Washer
(including fittings)
Acrylonitrile and Buna-N cover and tube
Synthetic yarn and EPDM
Anodized aluminum, Aluminum or bronze alloys, Brass Copper, Nylon– composite, Ceramic, Buna-N,
Cotton phenolic, 303, 304, and 316 Stainless steel, Polymide–12 thermoplastic, , Carbon steel, Zinc
with or without yellow chromate plate
