Pump Assembly – Parts
USE ONLY GENUINE GRACO PARTS AND ACCESSORIES
Models 800573 and 804578
REF PART
NO. NO. DESCRIPTION QTY
1 CRANKCASE 1
2 801484 PLUG 2
3 802344 O-RING 1
4 PROTECTOR 1
5 KIT 83 SEAL, Oil
6 PLUG 1
7 MANIFOLD 1
8 WASHER 8
9 SCREW 8
10 KIT 1 O-RING
11 KIT 1 SEAT, Valve
12 KIT 1 PLATE, Valve
13 KIT 1 SPRING
14 KIT 1 CAGE, Valve
15 KIT 84 O-RING
16 KIT 84 CAP, Valve
17 KIT 1 VALVE ASSEMBLY
18 KIT 96,97 RING, Head
19 KIT 96,97 PACKING
20 KIT 96 RETAINER, Packing
21 KIT 96,97 O-RING
22 KIT 96,97 O-RING
23 802345 GAUGE, Sight 1
24 BEARING 1
REF PART
NO. NO. DESCRIPTION QTY
25 801659 DIPSTICK 1
26 NUT 3
27 WASHER 3
28 PLUNGER 3
29 803918 O-RING 3
30 803919 RING, Back Up 3
31 WASHER, Flinger 3
32 PIN, Connecting Rod 3
33 COVER, Crankcase 1
34 SCREW 4
35 804015 GASKET, Cover 1
36 END, Connecting Rod 3
37 ROD, Connecting 3
49 SCREW 4
50 801652 WASHER 4
51 FLANGE 1
52 SCREW 4
53 WASHER 4
54 SPACER 1
55 803268 O-RING 1
56 804018 SEAL, Oil 1
57 RING, Snap 1
58 BEARING 1
59 CRANKSHAFT 1
Kit
No.
Repair Kit
Part No.
Ref
No. Description Qty.
1 801472
Valve
Assembly
10
11
12
13
14
or
17*
O-RING
SEAT, Valve
PLATE, Valve
SPRING
CAGE, Valve
VALVE ASSEMBLY
6
6
6
6
6
6
83 804033
Oil Seal
5 SEAL, Oil 3
84 804034
Valve Cap
15
16
O-RING
CAP, Valve
6
6
96 804036
Packing
Assembly
18
19
20
21
22
RING, Head
PACKING
RETAINER,
Packing
O-RING
O-RING
1
1
1
1
1
97 804037
Packing
18
19
21
22
RING, Head
PACKING
O-RING
O-RING
3
3
3
3
* Item 17 consists of items 10 through 14.
See Pump Assembly illustration on previous page.
