29
• BEFORE adjusting the head support height, have
your child lean forward slightly.
• Squeeze and pull up the red head support adjustment
handle (a) on top of seat until it locks into one of the
8 height positions (b).
• To lower, squeeze red head support adjustment handle
and push head support down.
• When head support is in lowest position, always pull
flap forward as shown. (c).
Rear-facing
• Head support should be positioned so the harness
straps are at or just below the shoulders.
• Make sure the head support does not touch the front
vehicle seat.
Forward-facing
• Head support should be positioned so that the harness
straps are at or just above the child’s shoulders,
20-65 lbs (9 - 30 kg).
Refer to page 28 for harness strap placement.
Adjusting Head Support
a
b
c
Flap
