12
1
18*
47
12
3
14
7*
9*
*8
*17
4
10
13
2
43
41
40
TI8219C
Apply high quality lithium grease.
Torque to 30-36 ft-lb (40.6-48.8 N•m).
Torque to 38-42 ft-lb (51.3-56.7 N•m).
Use 3/8 in. drive socket to fit in recess.
Torque to 20 ft-lb (27.1 N•m).
Fully tighten against muffler (15).
Installation order: two leather o-rings (8), one u-cup
(7) facing up, and one spiral ring (9). Installation order
changed with series H air motors.
