Graco N22DT0 - Page 33

Parts
311238ZAM 33
NXT Model 2200 Varying Parts
 Replacement Danger and Warning labels, tags, and cards are available at no cost.
* Parts included in Repair Kit NXT200 (purchase separately).
 Parts included in Low Noise Exhaust Conversion Kit NXT111 (purchase separately).
† Only used on original poppets (see F
IG. 13) made prior to mid-2009.
Ref. Description
Air Motor Part Numbers
QtyN22DN0 N22DT0 N22DH0 N22LN0 N22LT0 N22LH0 N22RN0 N22RT0 N22RH0
22 KIT, de-ice exhaust,
includes items 20, 25, 44,
56, 57
NXT110 NXT110 NXT110
1
23 KIT, remote exhaust;
includes items 20, 44
NXT105 NXT105 NXT105 1
24 KIT, low noise exhaust;
includes items 20, 22, 25,
44, 54, 55, 56, 57, 63
NXT104 NXT104 NXT104 1
25 SCREW, machine, hex
hd; 1/4-20 x 1 in. (25 mm)
120730 120730 120730 120730 120730 120730 2
30 COVER, top 15G377 15G576 15G379 15G377 15G576 15G379 15G377 15G576 15G379 1
33 ADAPTER, lift ring 15F772 15F772 15F772 1
35 SENSOR ASSEMBLY
287839 287839 287839 1
36 GUIDE, strain relief 120143 120143 120143 1
40 AIR VALVE ASSEMBLY;
see page 39
NXT107 NXT108 NXT109 NXT107 NXT108 NXT109 NXT107 NXT108 NXT109 1
45 SCREW, thread-forming;
1/4-20 x 1/2 in. (13 mm)
107257 107257 107257 1
107257 107257 107257 3
107257 107257 107257 4
54 DEFLECTOR 15H179 15H179 15H179 1
55 SCREW, thread-forming;
1/4-20 x 1/2 in. (13 mm)
107257 107257 107257 2
56 SEAL, exhaust 15H190 15H190 15H190 15H190 15H190 15H190
1
57 GASKET; buna-N 15K345 15K345 15K345 15K345 15K345 15K345 1
63 DIFFUSER, exhaust 15G689 15G689 15G689 1
64 O-RING 108014 108014 108014 108014 108014 108014 1
65 ADAPTER, lift ring 16D001 16D001
16D001 16D001 16D001 16D001 1
66 O-RING C20987 C20987 C20987 C20987 C20987 C20987 1
