Parts
311238ZAM 39
Air Motor Parts List (for use with Remote DataTrak)
The parts listed below are common to all NXT Model Air Motors using the remote DataTrak. Parts which vary by air
motor are found in the table at the bottom of this page.
Replacement Danger and Warning labels, tags, and cards are available at no cost.
* Parts included in Repair Kits NXT200 (N22LR0), NXT300 (N34LR0), NXT600 (N65LR0). Purchase separately.
Parts included in Low Noise Exhaust Conversion Kit NXT111 (purchase separately).
Parts included in Remote DataTrak Kit NXT406 (purchase separately). Kit also includes items 139 and 144 (see page 40).
† Only used on original poppets (see F
IG. 13) made prior to mid-2009.
Parts designated n/a are not available separately.
Air Motor Models
N22LR0
N34LR0
N65LR0
Ref. Part Description Qty
7* 161562 PACKING, V-block; nitrile 1
8* 15H610 PACKING, backup; leather 2
9* 16A026 RING, retaining 1
10 NXT106 BUMPER, piston; includes magnet 1
12 NXT100 POPPET; includes items 12a-12d 2
12a
NXT101
. O-RING; buna-N 1
12b . O-RING; buna-N 1
12c† . O-RING, backup; buna-N 1
12d . O-RING; buna-N 1
13 119050 BOLT, hex hd; 1/2-13 x 8 in. (203 mm) 4
14 15F639 NUT, with lockwasher; 1/2-13 4
18* 15F449 O-RING, end cap; nitrile 2
20 119990 O-RING; buna-N 1
21 15F931 RING, lift 1
24 NXT104 KIT, low noise exhaust; includes items
20, 25, 44, 54, 55, 56, 57, 63
1
25 120730 SCREW, machine, hex hd; 1/4-20 x 1
in. (25 mm)
5
40 NXT107 AIR VALVE ASSEMBLY; see page 39 1
41 120088 SCREW; 3/8-16 x 4 in. (101 mm) 4
43 120091 SCREW, thread forming; 1/4-20 x 2 in.
(51 mm)
4
44 120092 SCREW, thread forming; 1/4-20 x 2-1/2
in. (63 mm)
2
45 107257 SCREW, thread-forming; 1/4-20 x 1/2
in. (13 mm)
4
46* 253476 GASKET 1
47 15M568 COVER, valve, outer 1
51 15F674 LABEL, safety 1
54 15H179 DEFLECTOR 1
55 107257 SCREW, thread-forming; 1/4-20 x 1/2
in. (13 mm)
2
56 15H190 SEAL, exhaust 1
57 15K345 GASKET; buna-N 1
58 120206 MUFFLER, poppet 2
59 277366 BUMPER 1
60 116343 SCREW, ground; M5 x 0.8 1
61 111307 WASHER, lock; 5 mm 1
62 n/a PLUG 1
63 15G689 DIFFUSER, exhaust 1
64 108014 O-RING 1
65 16D001 ADAPTER, lift ring 1
66 C20987 O-RING 1
74 121162 CLIP, strain relief 1
75 117018 WASHER 1
76 15M573 WIRE HARNESS, remote 1
Ref. Part Description Qty
Ref. Description
Air Motor Part Numbers
QtyN22LR0 N34LR0 N65LR0
1 CAP, top 15F955 15F954 15F953 1
2 CYLINDER NXT204 NXT304 NXT604 1
3 COVER, bottom NXT202 NXT302 NXT602 1
4 PISTON ASSEMBLY; includes item 10 NXT201 NXT301 NXT601 1
15 MUFFLER NXT203 NXT303 NXT603 1
17* O-RING, piston; nitrile 123196 122434 122675 1
30 COVER, top 15G377 15G556 16R866 1
