Graco NAUTILUS Elite User Manual

10

1. Lay child restraint flat on back. Grab seat pad
fabric in sitting area to expose the gutters .
MAKE SUREDOOKDQGVILQJHUVDQGRWKHUREMHFWV
are clear of the gutters.
2. MAKE sure the harness straps are securely
attached within the “T”-shaped slots around the
arms as shown .
:LWK\RXURWKHUKDQGUDLVHVHDWEDFNVRWKDW
both arms LOCK into the gutters .
KEEP GUTTERS CLEAR
KEEP GUTTERS CLEAR
A r m
Harness Strap
T-slot
5.0 Assembling the Child Restraint
Adult assembly required.



Graco NAUTILUS Elite Specifications

General

Height Limit	27-57 inches
Harness Type	5-point harness
Recline Positions	3
Headrest Positions	10
Forward-facing Weight Capacity	22-65 lbs
Car Seat Weight	20.5 lbs
Warranty	1 year limited warranty
Installation	LATCH or seat belt
Booster Seat Weight Capacity	30-100 lbs
Booster Seat Height Capacity	Up to 57 inches
