1. Place booster seat firmly against the back of
a forward-facing vehicle seat equipped with a
lap/shoulder belt only.
2. Place child in car seat with child’s back flat
against back of car seat.
3. Position lap/shoulder belt through shoulder
belt guide  not underneath shoulder belt
guide . Belt should pass over vehicle belt
guide . Fasten buckle and pull up on the
shoulder belt to tighten.
4. IfEHOWOLHVDFURVVFKLOG¶VQHFNKHDGRUIDFH
redirect belt over shoulder by adjusting the
KHDGVXSSRUWVHWWLQJSee page 50, Adjusting
Head Support.
5. Check that shoulder belt is properly
positioned over shoulder and snug against
child. A snug strap should not allow any slack.
It lies in a relatively straight line without
sagging. It does not press on the child’s flesh
or push the child’s body into an unnatural
position.
15.0 Securing Child & Booster Seat in Vehicle




Graco NAUTILUS Elite Specifications

General

Height Limit	27-57 inches
Harness Type	5-point harness
Recline Positions	3
Headrest Positions	10
Forward-facing Weight Capacity	22-65 lbs
Car Seat Weight	20.5 lbs
Warranty	1 year limited warranty
Installation	LATCH or seat belt
Booster Seat Weight Capacity	30-100 lbs
Booster Seat Height Capacity	Up to 57 inches
