44
10. Remove harness straps from arms as
shown in
¢.
6WRUHWKHERG\VXSSRUWKDUQHVVFRYHUVFURWFK
pad cover and harness straps
in safe place for future use.
11. Move seat pad fabric out of the way then
raise seat back so that both arms LOCK into
the gutters .
You should hear a CLICK when the arms lock
into the gutters.
MAKE sure to keep the gutters clear of any
obstructions.
¢
11
Arm
Harness Strap
T-slot
KEEP
GUTTERS CLEAR
11

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Graco NAUTILUS Elite and is the answer not in the manual?

Graco NAUTILUS Elite Specifications

General IconGeneral
Height Limit27-57 inches
Harness Type5-point harness
Recline Positions3
Headrest Positions10
Forward-facing Weight Capacity22-65 lbs
Car Seat Weight20.5 lbs
Warranty1 year limited warranty
InstallationLATCH or seat belt
Booster Seat Weight Capacity30-100 lbs
Booster Seat Height CapacityUp to 57 inches
