Graco NAUTILUS Elite User Manual

50
16.0 Adjusting Head Support
When using with or without the built-in
harness.
BEFOREDGMXVWLQJWKHKHDGVXSSRUWKHLJKW
have your child lean forward slightly.
Squeeze the red adjustment handle
 on
top of seat and pull back support up until it
snaps into one of the 5 height positions.
7RORZHUVTXHH]HUHGDGMXVWPHQWKDQGOH
and push down.
CHECK to make sure it is securely snapped
into one of the 5 height positions by pulling
up on head support.
The shoulder belt guides must be even with
or just above the shoulders as shown by
dotted line
.



Graco NAUTILUS Elite Specifications

General

Height Limit	27-57 inches
Harness Type	5-point harness
Recline Positions	3
Headrest Positions	10
Forward-facing Weight Capacity	22-65 lbs
Car Seat Weight	20.5 lbs
Warranty	1 year limited warranty
Installation	LATCH or seat belt
Booster Seat Weight Capacity	30-100 lbs
Booster Seat Height Capacity	Up to 57 inches
