Graco NAUTILUS Elite User Manual

12

5. Pull elastic loop on the seat pad through the
vehicle belt guide on side of seat and attach to
hook as shown . Repeat on other side.
6. Squeeze height adjust button  and push
head support into slots  on the back support
as shown. Head support will click into the back
support.
You may need to unfasten the hook and loop
attachment tape on both sides at the top of
the back support to allow for easier access to
the slots.
Always use child restraint with head support
installed and properly adjusted.
CLICK!



Graco NAUTILUS Elite Specifications

General

Height Limit	27-57 inches
Harness Type	5-point harness
Recline Positions	3
Headrest Positions	10
Forward-facing Weight Capacity	22-65 lbs
Car Seat Weight	20.5 lbs
Warranty	1 year limited warranty
Installation	LATCH or seat belt
Booster Seat Weight Capacity	30-100 lbs
Booster Seat Height Capacity	Up to 57 inches
