Graco NAUTILUS User Manual

10

1. Lay child restraint flat on back. Grab seat pad
fabric in sitting area to expose the gutters .
MAKE SURE all hands, fingers and other objects
are clear of the gutters.
2. MAKE sure the harness straps are securely
attached within the “T”-shaped slots around the
arms as shown Ë.
With your other hand, raise seat back so that
both arms LOCK into the gutters Ì.
KEEP GUTTERS CLEAR
KEEP GUTTERS CLEAR
Arm
Harness Strap
T-slot
5.0 Assembling the Child Restraint
Adult assembly required.
Ë
Ì

Graco NAUTILUS Specifications

General

Age range	1 yr(s)
Car seat group	1-2-3 (9 - 36 kg; 9 months - 12 years)

Weight and Dimensions

Depth	480 mm
Width	500 mm
Height	880 mm
