16.0 Adjusting Head Support
When using with or without the built-in
harness.
BEFORE adjusting the head support height,
have your child lean forward slightly.
Squeeze the red adjustment handle
 on
top of seat and pull back support up until it
snaps into one of the 5 height positions.
To lower, squeeze red adjustment handle
and push down.
CHECK to make sure it is securely snapped
into one of the 5 height positions by pulling
up on head support.
The shoulder belt guides should be even
with or just above the shoulders as shown
by dotted line
Ë.

Ë

Graco NAUTILUS Specifications

General

Age range	1 yr(s)
Car seat group	1-2-3 (9 - 36 kg; 9 months - 12 years)

Weight and Dimensions

Depth	480 mm
Width	500 mm
Height	880 mm
