Graco NAUTILUS User Manual

22
8.5 With OR Without Built-in Harness
• Combination Lap/Shoulder Belt with
Locking Latch Plate
Once it is buckled, this type of belt has a
latchplate that will not allow the lap portion
of the belt to loosen. Belt is tightened by
pulling hard on the shoulder portion of the
vehicle belt while pushing down hard on
the child restraint.
• Combination Lap/Shoulder Belt with
Sliding Latch PlateThis belt has a
latchplate that slides freely along the belt.
• This belt MUST be converted to prevent
movement of the lap portion of the belt. You
must use the locking clip provided with the
child restraint, unless your vehicle's seat
belt can be converted in another way as
described in your vehicle owner's manual.
When using booster seat WITHOUT the
built-in harness, locking clip is NOT
to be used.
Locking clip

Graco NAUTILUS Specifications

General

Age range	1 yr(s)
Car seat group	1-2-3 (9 - 36 kg; 9 months - 12 years)

Weight and Dimensions

Depth	480 mm
Width	500 mm
Height	880 mm
