Graco NAUTILUS User Manual

45
10. Remove harness straps from arms as
shown in
Ó.
Store the body support, harness covers, crotch
pad cover and harness straps
in safe place for future use.
11. Move seat pad fabric out of the way then
raise seat back so that both arms LOCK into
the gutters .
You should hear a CLICK when the arms lock
into the gutters.
MAKE sure to keep the gutters clear of any
obstructions.
KEEP
GUTTERS CLEAR
Ó
11
Arm
Harness Strap
T-slot
11

Graco NAUTILUS Specifications

General

Age range	1 yr(s)
Car seat group	1-2-3 (9 - 36 kg; 9 months - 12 years)

Weight and Dimensions

Depth	480 mm
Width	500 mm
Height	880 mm
