Graco NAUTILUS User Manual

44
7. On the rear of the seat, detach 2 lower seat
pad elastic straps from hooks as shown in
.
8. Also detach the elastic straps that are
threaded through the vehicle belt guides on the
sides of the seat as shown in Ñ . Repeat on
other side.
9. Pull the seat pad out of the way to reveal the
red buttons as shown in the seating area Ò .
Slide the buttons to release the back support
from the base and lower it into a flat position.
Hold the back support to avoid it from falling
back and hitting something.

Ò
Ñ

Graco NAUTILUS Specifications

General

Age range	1 yr(s)
Car seat group	1-2-3 (9 - 36 kg; 9 months - 12 years)

Weight and Dimensions

Depth	480 mm
Width	500 mm
Height	880 mm
