Graco NAUTILUS User Manual

46
12. Tuck seat pad in between the gap of the
back support and seat area of the booster seat
to allow 2 elastic straps to show at the rear of
the seat.
13. Attach 2 seat pad elastic straps onto the
hooks on the rear of the child restraint as
shown in .
14. Pull elastic strap on the seat pad through
the vehicle belt guide on side of seat and
attach to hook as shown.
Repeat on other side .
Reverse instructions to reinstall harness.
See Section 10.0, page 30-35 for the correct
path for the harness.
12
12
13
13

Graco NAUTILUS Specifications

General

Age range	1 yr(s)
Car seat group	1-2-3 (9 - 36 kg; 9 months - 12 years)

Weight and Dimensions

Depth	480 mm
Width	500 mm
Height	880 mm
