8. Use plastic strap guides as
a guide to feed the harness up
over the red rollers. Make sure
to feed straps OVER red rollers
and plastic strap guides .
Make sure that the tether strap
does not interfere when
changing the harness strap
height positions.
9. If the straps are not fed
OVER the red rollers, the
assembly is incorrect and MUST
be corrected before using child
restraint.
10. Reassemble straps onto
metal junction plate exactly as
shown .
Check that straps are
completely within the slots
and that they are not twisted.
Harness
straps
MUST
go over
red rollers.
12
11
11
12

Graco NAUTILUS Specifications

General

Age range	1 yr(s)
Car seat group	1-2-3 (9 - 36 kg; 9 months - 12 years)

Weight and Dimensions

Depth	480 mm
Width	500 mm
Height	880 mm
