Graco NAUTILUS User Manual

65
Prevent serious injury or death:
• Buckle must be properly latched.
• Periodically inspect and clean buckle to remove
objects or debris that could prevent latching.
1. Turn restraint over, push retainer through crotch strap slot
.
2. To clean buckle - place in a cup of warm water and gently agitate
the buckle, press the red button several times while in the water
Ë. DO NOT SUBMERGE THE HARNESS WEBBING. DO NOT
USE SOAPS or LUBRICANTS. DO NOT use household detergents.
Never lubricate buckle.
3. Shake out excess water and allow to air dry, harness webbing
should be dry before use Ì.
4. Repeat Step 2 and 3 as needed. Buckle should fasten with a
“click”.
5. Re-attach buckle into the same slot from Step 1. Re-check
harness for correct installation before use.
23.1 Buckle Cleaning Process

Ë
Ì

Graco NAUTILUS Specifications

General

Age range	1 yr(s)
Car seat group	1-2-3 (9 - 36 kg; 9 months - 12 years)

Weight and Dimensions

Depth	480 mm
Width	500 mm
Height	880 mm
