Graco Reactor 2 - Replace Transformer; Replace Power Supply

Repair
Replace Replace
Replace
Transformer Transformer
Transformer
1.PerformShutdown,page50.
2.Removefourbolts(23)andshroud(10).
3.Removelowerdinrailcover(48).
4.Disconnectfanandtransformerconnections
fromterminalblocks.Connectionsareon
leftsidelabeled:V+,V-,1,2,3,and4.
5.Removefournuts(27)holdingmetal
transformercover(8)toframe.Carefully
removecoverwhileslidingwiresthrough
holeincover.
6.Removenuts(27)andtransformer(17).
7.Installtransformer(17)inreverseorder.
Replace Replace
Replace
Power Power
Power
Supply Supply
Supply
1.PerformShutdown,page50.
2.Disconnectinputandoutputcablesfrom
bothsidesofthepowersupply(805).See
ElectricalSchematics,page105.
3.Insertaatheadscrewdriverinthe
mountingtabonthebottomofthepower
supply(805)toremovefromthedinrail.
4.Installnewpowersupply(805)inreverse
order.
Figure924VDCPowerSupply
334946J
71
