7 Moving
LATCH
7-A
Moving the LATCH Strap
1. For Ease of Moving the LATCH Strap
A. Loosen the harness straps.
B. Raise the headrest to the highest
position.
C. Unbuckle the chest clip.
D. Unbuckle the buckle.
2. Remove the Lower Seat Pad to
Expose the LATCH Strap
Note the orange and blue labels at the top
and bottom of the red bar (G).
E
F
G
39
A
B
C
D
To Next Page
