Graco SLIMFIT - Headrest Pillow; Cup Holder

To Next Page

To Previous Page

Accessories

Headrest Pillow

Style A. To remove, pull out the pillow out.

Cup Holder

To use cup holder, lift the inside cup (A)

and rotate until it locks into place (B).
