18
To Install Locking Clip: (DO NOT use with base)
1. Tighten the buckled belt by pushing down
hard on the child restraint and pulling hard
on the shoulder belt.
2. While pushing down on child restraint, pinch
the two straps together behind the buckle
tongue. Unbuckle the belt
without allowing it to slip.
3. Connect lap and shoulder belts
with locking clip as shown
and .
4. Rebuckle belt. Check that lap belt does
not move by pulling and
pushing hard on child restraint.
If belt loosens or lengthens,
repeat procedure.
Locking clip
Locking clip goes here,
1
/2 inch (1 cm) from the buckle
Combination Lap/Shoulder
Belt with Sliding Latch
Plate
This belt has a latch plate that slides
freely along the belt.
This belt MUST be converted to prevent
movement of the lap portion of the belt.
You must use a locking clip (provided
with the child restraint) when using the
child restraint without the base unless
your vehicle’s seat belt can be
converted in another way as described
in your vehicle owner’s manual.
1
/2 inch
(1 cm)
