22
LATCH
Connector
*
LATCH
Storage
Lock-off
United States Federal Motor Vehicle Safety Standards have defined a
system for installing car seats in vehicles. The system is called LATCH.
* LATCH may be used IN PLACE of vehicle belt ONLY if vehicle is
equipped with LATCH anchor points. Please refer to vehicle owner’s
manual for LATCH locations.
BASE
LATCH
Adjustment
Belt
Footrest
Recline adjustment
buttons
Level indicator
**
Footrest
**Level
Indicator
The level indicator is attached to the side of
the base and indicates whether or
not the child restraint is properly reclined.
Instruction
manual
storage
